2024 Grizzly 700 EPS XT-R

£14,760.00

2024 Grizzly 700 EPS XT-R Promotions


Model Description


A force of nature.

Yamaha’s industry-leading Ultramatic® transmission automatically selects the optimum gearing for all types of terrain, while the natural all-wheel engine braking gives huge confidence in downhill descents – and the On-Command® drive system allows you to switch seamlessly between 2WD, 4WD and Diff-lock at the push of a button.

Electronic Power Steering gives a natural feedback for enhanced comfort and control – and with its 4-wheel disc brake system and adjustable independent suspension, the super-tough Grizzly 700 EPS XT-R (Special Edition) is ready to take on the most challenging terrain. Discover this true force of nature.

For all you #DRIVENBYFREEDOM enthusiasts who look for a machine with unique touches, the Grizzly 700 EPS XT-R is the Special Edition of our toughest, compact off roader. With its gutsy 686cc engine and rugged chassis, this Grizzly gives you more freedom to explore – on the trail, through the hills or deep in the woods.

Colours

Titan/Tactical Black

Details

  • High Performance ATV = true All-Terrain Vehicle
  • Driver selectable wheel drive system
  • Excellent trail and off-trail handling
  • High-performance true All-Terrain Vehicle (ATV)
  • Excellent trail and off-trail handling
  • Long stroke terrain capable and comfy suspension
  • Four powerful and consistent hydraulic disc brakes
  • Well-balanced ride dynamics
  • Less fatigue and more precise handling by EPS
  • Connected rider forward ergonomics
  • Professional capacity for stowing and towing cargo
  • Sophisticated painted XT-R body & 27” X-TR wheels
  • Yamaha quality with high reliability

Model Specification


  • Engine

    Engine Type

    Single cylinder, liquid-cooled, 4-stroke, SOHC, 4-valves

    Fuel System

    Electronic Fuel Injection

    Starter System

    Electric

    Displacement

    686cc

    Bore x stroke

    102.0 mm x 84.0 mm

    Compression Ratio

    10.0 : 1

    Lubrication System

    Wet sump

    Ignition System

    TCI

    Drive system

    On-Command® 2WD/4WD/diff-lock

    Final transmission

    Shaft

  • Frame

    Front suspension system

    Independent double wishbone, 193 mm wheel travel, 5 position preload adjustment

    Rear suspension system

    Independent double wishbone, 232 mm wheel travel, 5 position preload adjustment

    Front brake

    Dual ventilated hydraulic disc

    Rear brake

    left hand/right foot operation, Ventilated hydraulic disc

    Front tyres

    Maxxis 27" Zilla tyres 27x 10-14, aluminium wheels

    Rear tyres

    Maxxis 27" Zilla tyres 27x 10-14, aluminium wheels

  • Dimensions

    Overall length

    2,070 mm

    Overall width

    1,230 mm

    Overall height

    1,253 mm

    Seat height

    860 mm

    Wheelbase

    1,253 mm

    Minimum ground clearance

    300 mm

    Min. turning radius

    3.5m

    Fuel tank capacity

    18.0 litres

    Oil tank capacity

    2.6 litres

  • Performance

    Front rack

    50 kg

    Rear rack

    90 kg

  • Wheels

    Steering system

    Ackermann-type with Electronic Power Steering
