2026 Wolverine® RMAX™2 850 XT-R

£TBC

Make an Enquiry Test Ride Enquiry Part Exchange Enquiry

2026 Wolverine® RMAX™2 850 XT-R Promotions


Model Description..


SHARE YOUR ADVENTURES.

The Wolverine® X2 850 XT-R, with its short wheelbase, high torque engine and compact chassis, is built to take you and your passenger across extreme terrain. With its exciting ergonomic design, this user-friendly Side-by-Side delivers even more comfort with its capability. #DRIVENBYFREEDOM.

Featuring high-back seats for two adults this machine delivers true comfort. The compact chassis gives outstanding agility and manoeuvrability – and the powerful torque of the 850cc engine offers easy low-speed control.

With a smooth-running Ultramatic® transmission and our switchable On-Command® drive system with 2WD/4WD/diff-lock, the Wolverine X2 850 XT-R gives you ultimate confidence and control.

COLOUR

Moss Grey / Tactical Black

AT A GLANCE

  • Powerful 850cc twin cylinder engine
  • Ultramatic® CVT transmission
  • On-Command® 2WD/4WD system
  • KYB Piggy-Back Shocks front & rear
  • Compact and agile chassis
  • Quiet and comfortable interior
  • Full-size high-back seats
  • Adaptable and versatile layout
  • Speed Management Key
  • XT-R capable and aggressive package

    • Model Specification


    • Engine

      Engine Type

      Liquid-cooled, 4-stroke, DOHC, Parallel Twin

      Fuel System

      Mikuni fuel injection with Drive by wire, dual 36mm throttle bodies

      Starter System

      Electric

      Displacement

      847cc

      Bore x Stroke

      93mm x 73.5mm

      Compression Ratio

      11.2 : 1

      Lubrication System

      Dry sump

      Ignition System

      TCI

      Transmission System

      Yamaha Ultramatic® CVT automatic V-belt all-wheel engine braking (L/H/N/R)

      Drive System

      On-Command® 2WD, 4WD, 4WD with Diff-lock

      Final Transmission

      Shaft

      Rear Suspension System

      Independent Double Wishbone, 429mm of wheel travel /FOX QS3 piggy back shocks

    • Suspension

      Front Suspension System

      Independent Double Wishbone with Anti-Sway Bar, 221mm of wheel travel. KYB Piggy back shocks with threaded spring preload, Hi & Low speed compression and rebound adjustment.

    • Brakes

      Front Brake

      Dual hydraulic disc

      Rear Brake

      Dual hydraulic disc, Shaft mounted parking brake

    • Wheels

      Front Tyres

      27" Dirt Commander tyres / 12" Aluminium rims

      Rear Tyres

      27" Dirt Commander tyres / 12" Aluminium rims

    • Frame

      Overall Length

      2,920mm

      Overall Width

      1,580mm

      Steering system

      Rack and Pinion Steering Assembly with selectable Electric Power Steering

      Towing capacity

      907kg

    • Dimensions

      Overall Height

      1,913mm

      Seat Height

      803mm

      Wheelbase

      2,125mm

      Min. turning radius

      4,800mm

      Wet weight (including full oil and fuel tank)

      719.5kg

      Fuel tank capacity

      35l

      Oil tank capacity

      4.1l

      Cargo bed

      272kg
