2023 Wolverine® RMAX™4 1000


2023 Wolverine® RMAX™4 1000 Promotions

Model Description

Reimagine everything.

The Wolverine® RMAX™4 1000 offers unprecedented style and comfort, but also expands your horizons, enabling you to take friends and family out for an exhilarating day of all-terrain adventures. New experiences will be easier to find too, thanks to the amazing new on-board features and sophisticated control systems.

The Wolverine® RMAX™ 1000 family follows our development philosophy of “Jin-Ki Kanno” – which translates from Japanese as “the true exhilaration of being one with the machine” – to bring you a super-capable off-roader, in which driver and passengers feel confident to master the very toughest terrain.


  • Brutal, class-leading 999cc machine
  • Fully loaded with Yamaha Off-Road technology
  • Top-level capability with an imposing stance
  • Next Generation design & aggressive styling
  • Four comfortable, full-size, high-back bucket seats
  • Yamaha quality with high reliability

Model Specification

  • Engine

    Engine Type

    Liquid-cooled, 4-stroke, DOHC, Parallel Twin

    Fuel System

    Mikuni fuel injection with dual 48mm throttle bodies

    Starter System




    Bore x Stroke

    93 mm x 73.5 mm

    Compression Ratio

    11.2 : 1

    Lubrication System

    Dry sump

    Ignition System


    Transmission System

    Yamaha Ultramatic® CVT automatic V-belt

    Drive System

    On-Command® 2WD, 4WD, 4WD with Diff-lock

    Final Transmission


    Rear Suspension System

    Independent Double Wishbone with Anti-Sway Bar, 337 mm of wheel travel /FOX QS3 piggy back

  • Suspension

    Front Suspension System

    Independent Double Wishbone with Anti-Sway Bar, 361 mm of wheel travel /FOX QS3 piggy back

  • Brakes

    Front Brake

    Dual ventilated hydraulic disc

    Rear Brake

    Dual ventilated hydraulic disc, Shaft mounted parking brake

  • Wheels

    Front Tyres

    AT29 x 9-14 GBC® Dirt Commander®

    Rear Tyres

    AT29 x 11-14 GBC® Dirt Commander®

  • Frame

    Overall Length

    3,255 mm

    Overall Width

    1,677 mm

    Steering system

    Rack and Pinion Steering Assembly with Electric Power Steering

    Towing capacity

    907 kg

  • Dimensions

    Overall Height

    2,110 mm

    Seat Height


    2,290 mm

    Min. turning radius

    6 m

    Wet weight (including full oil and fuel tank)

    930 kg

    Fuel tank capacity

    35 litres

    Oil tank capacity

    5.5 litres

    Cargo bed

    272 kg
