Model Description


R History. Your Future.

Designed specifically for supreme performance on the racetrack, the Yamaha R1M is equipped with highly sophisticated electronic control technologies that enable you to push even harder and discover your true potential.

Yamaha has created the race-focused R1M using some of the most sophisticated technology developed from the race-winning M1 MotoGP bike. Its state-of-the-art Öhlins Electronic Racing Suspension (ERS) with NPX anti-cavitation gas front forks bring out your best performance at every circuit – and the low frontal area carbon bodywork helps to shave your lap times.

But what really makes the R1M such a game-changer are the high-tech rider aids including Brake Control, Engine Brake Management and Launch Control – as well as a Communication Control Unit for datalogging and wireless engine tuning. Featuring full black rims, carbon body panels as well as black/silver tank colouring and latest graphics, the R1M is the ultimate R-Series delivering the most complete racetrack package.

Colours

Icon Performance

Generate a Finance Quote

New model finance is calculated off the models paint colour or finish, please select your desired colour below to return a more accurate finance quote.


Model Specification


  • Engine

    Engine Type

    4-stroke, Liquid-cooled, 4-cylinder, DOHC, 4-valves

    Displacement

    998 cc

    Bore x Stroke

    79.0 x 50.9 mm

    Compression Ratio

    13.0 : 1

    Maximum Power

    147.1 kW (200.0 PS) @ 13,500 rpm

    Maximum Torque

    113.3 Nm (11.6 kg-m) @ 11,500 rpm

    Starter System

    Electric

    Transmission

    Constant mesh, 6-speed

    Lubrication System

    Wet sump

    Clutch Type

    Wet, Multiple Disc

    Ignition System

    TCI

    Final Transmission

    Chain

    Fuel Consumption

    6.8 l / 100 km

    CO2 Emissions

    159 g / km

    Fuel System

    Electronic Fuel Injection

  • Dimensions

    Oil Tank Capacity

    4.9 l

    Fuel Tank Capacity

    17 l

    Length (mm)

    2,055 mm

    Width (mm)

    690 mm

    Height (mm)

    1,165 mm

    Wheel Base (mm)

    1,405 mm

    Weight (kg)

    202 kg

    Ground Clearance (mm)

    130 mm

  • Frame

    Front Tyre

    120/70 ZR17M/C (58W) Tubeless

    Rear Tyre

    200/55 ZR17M/C (78W) Tubeless

    Frame

    Aluminium Deltabox, Diamond

    Caster Angle

    24º

    Trail

    102 mm

    Front Suspension System

    Upside-down forks

    Rear Suspension System

    Link suspension, Swingarm

    Front Travel

    120 mm

    Rear Travel

    120 mm

    Front Brake

    Hydraulic dual discs, Ø320 mm

    Rear Brake

    Hydraulic single disc, Ø220 mm
