FT25
This is a previous model year that we don't stock.
Please use the menu above to browse our in stock and current models.
Model Description
Harness a high-thrust workhorse
When you want raw power and precise handling, FT models are the perfect answer. Ideal for sailing, fishing and working boats, these high-thrust, high-torque engines set new standards of performance, with minimal noise and vibration – and maximum fuel economy.
FT models use Yamaha’s patented Dual-Thrust propeller to provide full thrust in Forward and Reverse – making light work of manoeuvring a heavy boat.
CDI/TCI Micro-computer Ignition offers easy starting and reliability whatever the conditions, and high-output alternators provide extra starting power, even after long periods at low RPM. FT Series engines are big, powerful workhorses – designed never to let you down.
special gear ratios for higher thrust
Dual-Thrust prop – high-thrust in Forward/Reverse
EFI (FT60/50) for low emissions & fuel efficiency
High-output alternator
CDI Ignition (FT25/FT9.9/8),TCI Ignition (FT60/50)
Wide Range Power Trim & Tilt (FT60/50/25)
Yamaha’s immobiliser security system (FT60/FT50)
Power tilt (FT9.9/FT8)
Model Specification
-
Engine
Max Thrust (kg)
Amp Draw
Voltage
Engine Type
Four Stroke
Displacement
498 cm3
No. of cylinders/configuration
2/In-line
Bore x stroke
65.0 mm x 75.0 mm
Prop shaft output at mid range
18.4kW / 5,500 rpm
Full throttle operating range
5,000 - 6,000 rpm
Lubrication system
Wet sump
Carburettors
1 carb.
Ignition / advance system
CDI Micro-Computer
Starter system
Electric
Gear ratio
2.42 (29/12)
Fuel tank capacity
separate, 25 litres
Steering
Remote Control
Throttle and shift controls
Remote Control
Lighting Coil / Alternator
12V - 14A
Propeller
Included
Control
Trim and tilt method
Valves
Cam
-
Dimensions
Weight
Recommended boat transom height
L:508mm
Oil pan capacity
1.4 litres
Shaft Length
L
Weight without propeller
-
Other
Warranty
