F9.9J
This is a previous model year that we don't stock.
Please use the menu above to browse our in stock and current models.
Model Description
The lightweight heavyweights
Packing power on the water doesn’t have to mean dragging a bulky, heavy outboard onto your boat because the lightweight F8 and F9.9 are perfectly portable. Their comfortable-to-use integrated carrying handles help too.
Discover the joys of whisper-quiet operation and excellent fuel economy, blended with smooth, reliable power and impressive torque. Yamaha’s CDI Ignition System ensures reliable, first-time start-up, so with the twist-grip throttle and F-N-R gear system, it all adds up to easy, safe handling.
These are engines with many talents, making them ideal for tender duties, for short fishing or family expeditions – or if you use your boat as a reliable work partner.
Details
Compact and efficient engine design
CDI Ignition for easy starting in all conditions
Strong tiller handle with twist-grip throttle
Forward-Neutral-Reverse gears for easy control
Fresh water flushing system option
Yamaha Ideal Anti-corrosion Protection
Shallow Water Drive for cruising close inshore
The quietest engines in their class
Reliable power and impressive torque
Outstanding fuel economy
Low exhaust emissions for clean cruising
Start-in-gear’ protection
Model Specification
-
Engine
Max Thrust (kg)
Amp Draw
Voltage
Engine Type
Four Stroke
Displacement
212 cc
No. of cylinders/configuration
2
Bore x stroke
56.0 mm x 43.0 mm
Prop shaft output at mid range
7.3kW / 5,500 rpm
Full throttle operating range
5,000 - 6,000 rpm
Lubrication system
Wet sump
Carburettors
1 carb.
Ignition / advance system
CDI Micro-Computer
Starter system
Electric (FE), Manual (FM)
Gear ratio
2.08 (27/13)
Fuel tank capacity
separate, 12 litres
Steering
Tiller (FMH), Remote control (FE)
Throttle and shift controls
Twist grip (FMH), FNR/side shift (FMH), Single lever remote control (FE)
Lighting Coil / Alternator
12V - 6A with rectifier/regulator
Propeller
Included
Control
Trim and tilt method
Valves
Cam
-
Dimensions
Weight
Recommended boat transom height
S:381mm L:508mm
Oil pan capacity
0.8 litres
Shaft Length
S / L
Weight without propeller
-
Other
Warranty
