Model Description..
Available in Tiller or Remote control variants with Power Trim and Tilt. Micro-computer controlled EFI, Digital Network Gauges.
Model Specification
-
Engine
Max Thrust (kg)
Amp Draw
Voltage
Engine Type
SOHC, 6 Valve
Displacement
747 cc
No. of cylinders/configuration
3
Bore x stroke
65.0 mm x 75.0 mm
Prop shaft output at mid range
29.4kW / 5,500 rpm
Full throttle operating range
5,000 - 6,000 rpm
Lubrication system
Wet sump
Carburettors
Ignition / advance system
CDI Micro-Computer
Starter system
Electric (FE)
Gear ratio
2.00 (26/13)
Fuel tank capacity
separate, 25 litres
Steering
Tiller handle (FEHD), Remote control (FET + FED)
Throttle and shift controls
Twist grip (FEH), Single lever remote control (FE)
Lighting Coil / Alternator
12V - 17A
Propeller
Options available
Control
Trim and tilt method
Valves
6
Cam
Single Over Head
-
Dimensions
Weight
Recommended boat transom height
S:381mm L:508mm
Oil pan capacity
1.5 litres
Shaft Length
S / L
Weight without propeller
-
Other
Warranty
